MM 850nm Rack Mount Media Converter , Media Converter Rack Full / Half Duplex Self Adapt

MM 850nm Rack Mount Media Converter , Media Converter Rack Full / Half Duplex Self Adapt

MM 850nm Rack Mount Media Converter , Media Converter Rack Full / Half Duplex Self Adapt

Product Details:

Place of Origin:	SHENZHEN,CHINA
Brand Name:	NEWBRIDGE
Certification:	FCC,CE
Model Number:	ND-E1 MM/ST

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	Negotiation
Packaging Details:	packing can be done by customer's requested, usually used in carton
Delivery Time:	According to the quantiy and stocking , 3-4 working days after payment
Payment Terms:	T/T , Western Union
Supply Ability:	According to the different products , the monthly output is different

Contact Now

Detailed Product Description

Size:	227× 147 ×42mm	Humidity:	5-90%
Power Supply:	DC5V 1A	Operating Temperature:	0° C ~ 50°C
Storage Temperature:	-40℃—70℃	Power Consumption:	＜15W

E1 fiber modem, MM ,850 nm, ST, 2KM G 7.03 Standard , Rack Mount Media Converter

Feature

◆ Transparent transfer E1 to Ethernet interface

◆ Have 2 loop back functions: E1 local loop, E1 external loop

◆ E1 interface compatible with ITU-T G.703,G.704,and G.823.

◆ Support E1 channel hot plug, and auto detect available E1 channels not pause the transmission

◆ E1 Support 75Ω/unbalance impedance or 120Ω/balance

◆ 10M/100M Ethernet, full/half duplex self adapt, support VLAN

◆ Ethernet support AUTO-MDIX

◆ Support Dynamic Ethernet MAC address(4096), having local address filter function

Specification

>> E1 (G.703) Interface:

Connector: 2 BNC (75 ohm, unblance)

1RJ45(120 ohm, blance)

Encoding: HDB3

Rate:2.048M bps ±50ppm

Jitter Tolerance: comply with G.823

>> Optical interface:

Connector :SC/FC

Rate:10/100 auto-negotiation

Optical code:CMI

Wavelength:1300nm for multi-mode fiber

1310nm for single-mode fiber

Working Temperature:0—50℃

Storage Temperature: -40℃—70℃

Humidity: 5-90%(non-condensing)

EMI : Comply with FCC part 15 Class A and CE mark

Power supply: AC 100V--260V 50-60Hz, DC 5V,1A

Size: 227× 147 ×42mm (External power supply)

Order info

Part No	Description of product
ND-E1 MM/ST	E1 fiber modem, MM ,850 nm, ST, 2KM

Tag:

media converter rack,

fiber optic media converter rack
