Mini Managed PoE Switch Optional Ethernet Channel E1 Backup 16 Port PCM Multiplexer

Mini Managed PoE Switch Optional Ethernet Channel E1 Backup 16 Port PCM Multiplexer

Mini Managed PoE Switch Optional Ethernet Channel E1 Backup 16 Port PCM Multiplexer

Product Details:

Place of Origin:	SHENZHEN,CHINA
Brand Name:	NEWBRIDGE
Certification:	FCC,CE
Model Number:	ND-480-LM

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	Negotiation
Packaging Details:	packing can be done by customer's requested, usually used in carton
Delivery Time:	According to the quantiy and stocking , 3-4 working days after payment
Payment Terms:	T/T , Western Union
Supply Ability:	According to the different products , the monthly output is different

Contact Now

Detailed Product Description

Size:	482×200×45mm	Port:	16
Bit Rate:	150Mb/s+/-50ppm	Connector:	FC/SC
Power Supply:	＜15W	Operating Temperature:	0° C To + 50°C

16 E1 PDH Multiplexer, E1 Backup + 16 port PCM Multiplexer

Feature

◆ Multiplex 16E1 into one fiber channel to transmit

◆ Offer 1 optional 10/100Mbps Ethernet channel

◆ RS232 asynchronous interface, for management

◆ Complete alarm function and state indicator

◆ Support the local/remote E1 loop back

◆ E1 Line code: HDB3, compliant to G.703, G.823 and G.742

◆ E1 channel support both 75ohm & 120ohm impedance

Specification

>> E1 Port

Port number: 16

Bit rate: 2.048Mbps (+/-100ppm)

Impedance: 75ohm or 120ohm

Line Code: HDB3, compliant with ITU-T G.703

>> OPtical Port

Bit rate: 150Mb/s+/-50ppm

Wavelength: 1310nm, 1550nm

Connector: FC/SC

>> power supply

Input voltage:When -48V, -40V ～ -60V (DC) is allowed

When ~220V, 175V ～ ~264V (AC) is allowed.

Power Consumption :less than 15 watts

Operating Temperature: 0° C to + 50°C

Storage Temperature: - 40° C to + 75°C

Humidity: 5%-95% Non-Condensing

Size: 482×200×45mm

Order info

Part No	Description of product
ND-480-LM-F22	16 E1 PDH Multiplexer,FC,AC220V, 40KM
ND-480-LH-F48	16 E1 PDH Multiplexer,FC,DC-48V, 60KM
ND-480-LH-F24	16 E1 PDH Multiplexer,FC,DC+24V, 60KM
