Duplex LC Fiber Optic Transceiver Module 850/900nm 40Gb/s Bidi QSFP+ 3.5 Watt

Product Details:

Place of Origin:	SHENZHEN,CHINA
Brand Name:	NEWBRIDGE
Certification:	FCC,CE
Model Number:	NDQP-40G-SR-BD

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	Negotiation
Packaging Details:	packing can be done by customer's requested, usually used in carton
Delivery Time:	According to the quantiy and stocking , 3-4 working days after payment
Payment Terms:	T/T , Western Union
Supply Ability:	According to the different products , the monthly output is different

Contact Now

Detailed Product Description

Fiber:	Single Fiber	Device Type:	Optical SFP Module
Data Rate:	40G	Operating Temperature:	0°C To 70°C
Power Supply:	+3.3V	Low Power Consumptionor:	<3.5W

NDQP-40G-SR-BD is a Four-Channel QSFP+ package optical transceiver for 40 Gigabit Ethernet Applications. It multiplexes internally an XLPPI 4x10G interface into two 20Gb/s electrical channels, transmitting and receiving data at 850 and 900nm wavelength, up to the distance of 100m on OM3 / 150m on OM4. It is a high performance module for short-range duplex data communication and interconnection applications.

Features: Duplex LC Fiber Optic Transceiver Module 850/900nm 40Gb/s Bidi QSFP+ 3.5 Watt

Four lane aggregated bandwidth up to 40Gbps
10.3125 Gbps per electrical channel with 64b/66b encoded data
Hot-pluggable
Duplex LC
^² 100m on OM3 / 150m on OM4
Compliant with QSFP+ SFF-8436 Specification
Compliant with QSFP MSA
Compliant witch 40GbE XLPPI electrical specification per IEEE 802.3ba-2010
Built-in digital diagnostic functions
Power Supply :+3.3V
Power consumption: <3.5W
Temperature Range: 0~ 70°C
RoHS Compliant

Applications:

Duplex LC Fiber Optic Transceiver Module 850/900nm 40Gb/s Bidi QSFP+ 3.5 Watt

^² 40GBASE Ethernet

^² Fiber channel

^² Data center

Ordering Information:

Duplex LC Fiber Optic Transceiver Module 850/900nm 40Gb/s Bidi QSFP+ 3.5 Watt

Part Number	Data Rate	Distance	Wavelength	Fiber	DDM	Connector

SHQP-40G-SR-BD	40Gb/s	100m	850/900nm	MM	Yes	Duplex LC

Duplex LC Fiber Optic Transceiver Module 850/900nm 40Gb/s Bidi QSFP+ 3.5 Watt

Absolute Maximum Ratings

Parameter	Symbol	Min.	Typical	Max.	Unit
Storage Temperature	TS	-40		+85	°C

Supply Voltage	VCCT, R	-0.5		4	V

Relative Humidity	RH	0		85	%

Recommended Operating Environment:

Parameter	Symbol	Min.	Typical	Max.	Unit
Case operating Temperature	TC	-5		+70	°C

Supply Voltage	VCCT, R	+3.135		+3.465	V

Supply Current	ICC			1000	mA

Power Dissipation	PD			3.5	W

Electrical Characteristics (TOP = 0 to 70 °C, VCC = 3.135 to 3.465 Volts)

Parameter	Symbol	Min	Typ	Max	Unit	Note

Data Rate per Channel		-	10.3125	11.2	Gbps

Power Consumption		-	2.5	3.5	W

Supply Current	Icc		0.75	1.0	A

Control I/O Voltage-High	VIH	2.0		Vcc	V

Control I/O Voltage-Low	VIL	0		0.7	V

Inter-Channel Skew	TSK			150	Ps

RESETL Duration			10		Us

RESETL De-assert time				100	ms

Power On Time				100	ms

Transmitter

Single Ended Output Voltage Tolerance		0.3		4	V	1

Common mode Voltage Tolerance		15			mV

Transmit Input Diff Voltage	VI	120		1200	mV

Transmit Input Diff Impedance	ZIN	80	100	120

Data Dependent Input Jitter	DDJ			0.1	UI

Data input total jitter	TJ			0.28	UI

Receiver

Single Ended Output Voltage Tolerance		0.3		4	V

Rx Output Diff Voltage	Vo		600	800	mV

Rx Output Rise and Fall Voltage	Tr/Tf			35	ps	1

Total Jitter	TJ			0.7	UI

Notes: 1. 20%~80%.

Duplex LC Fiber Optic Transceiver Module 850/900nm 40Gb/s Bidi QSFP+ 3.5 Watt

Optical Parameters (T_OP = 0 to 70°C, VCC = 3.135 to 3.465 Volts)

Parameter

Symbol

Min

Typ

Max

Unit

Ref.

Transmitter

Optical Wavelength

Channel 1

832

850

868

Channel 2

882

900

918

Average output power per channel

Pavg

-4

+5.0

dBm

Laser off power per channel

Poff

-30

dBm

Optical Extinction Ratio

3.5

RMS Spectral width

Δλ

0.65

Relative intensity noise

RIN

-128

Db/Hz

Optical return Loss tolerance

Receiver

Optical Wavelength

Channel 1

882

900

918

Channel 2

832

850

868

Receiver Sensitivity per channel

Sen

-11

dBm

Maximum Input Power

PMAX

0.5

dBm

Receiver reflectance

Rrx

-12

LOS De-Assert

LOSD

-14

dBm

LOS Assert

LOSA

-30

dBm

LOS Hysteresis

LOSH

0.5

Notes: 1. 12dB reflection.

Pin Function Definitions

Pin		Logic		Symbol		Name/Description		Note
1			GND		Ground			1

2	CML-I		Tx2n		Transmitter Inverted Data Input

3	CML-I		Tx2p		Transmitter Non-Inverted Data output







							Page: 3 / 9

	SH LINK CO., LIMITED		\|Optical Transceiver Datasheet\|

4		GND	Ground	1

5	CML-I	Tx4n	Transmitter Inverted Data Output

6	CML-I	Tx4p	Transmitter Non-Inverted Data Output

7		GND	Ground	1

8	LVTTL-I	ModSelL	Module Select

9	LVTTL-I	ResetL	Module Reset

10		VccRx	+3.3V Power Supply Receiver	2

11	LVCMOS-I/O	SCL	2-Wire Serial Interface Clock

12	LVCMOS-I/O	SDA	2-Wire Serial Interface Data

13		GND	Ground	1

14	CML-O	Rx3p	Receiver Inverted Data Output

15	CML-O	Rx3n	Receiver Non-Inverted Data Output

16		GND	Ground	1

17	CML-O	Rx1p	Receiver Inverted Data Output

18	CML-O	Rx1n	Receiver Non-Inverted Data Output

19		GND	Ground	1

20		GND	Ground	1

21	CML-O	Rx2n	Receiver Inverted Data Output

22	CML-O	Rx2p	Receiver Non-Inverted Data Output

23		GND	Ground	1

24	CML-O	Rx4n	Receiver Inverted Data Output

25	CML-O	Rx4p	Receiver Non-Inverted Data Output

26		GND	Ground	1

27	LVTTL-O	ModPrsL	Module Present

28	LVTTL-O	IntL	Interrupt

29		VccTx	+3.3V Power Supply Transmitter	2

30		Vcc1	+3.3V Power Supply	2

31	LVTTL-I	LPMode	Low Power Mode

32		GND	Ground	1

33	CML-I	Tx3p	Transmitter Inverted Data Output

34	CML-I	Tx3n	Transmitter Non-Inverted Data Output

35		GND	Ground	1

36	CML-I	Tx1p	Transmitter Inverted Data Output

37	CML-I	Tx1n	Transmitter Non-Inverted Data Output

38		GND	Ground	1
