4A B Building Zhuao Industrial Park Gushu Xixiang Baoan District Shenzhen,China,518126 | info@newbridge.com.cn |
Place of Origin: | SHENZHEN,CHINA |
Brand Name: | NEWBRIDGE |
Certification: | FCC,CE |
Model Number: | ND-6110 |
Minimum Order Quantity: | 1PC |
---|---|
Price: | Negotiation |
Packaging Details: | packing can be done by customer's requested, usually used in carton |
Delivery Time: | According to the quantiy and stocking , 3-4 working days after payment |
Payment Terms: | T/T , Western Union |
Supply Ability: | According to the different products , the monthly output is different |
Size: | 112× 117×25mm | InputInterface: | 2 HDMI |
---|---|---|---|
PowerSupply: | 12VDC | PowerConsumption: | 3~6 Watts |
StorageTemperature: | -30°C~70°C/-22°F~158°F | RelativeHumidity: | 20~90%RH |
2018 Top Quality 1080p to 1080i HD SDI Converter HDMI TO SDI Converter
Newbridge® NB6110B HDMI to SD HD 3G-SDI Converter is mainly used in converting one channel High Definition Multimedia Interface (HDMI) signal to serial Digital Interface (HD-SDI) signal The device integrates SDI transmitter and HDMI demodulator ,and simultaneously separate and convert HDMI audio signal, then embed it to HD-SDI signal to achieve the sound and image synchronization transmission
Feature
◆ Support series connection function in Transmitter and Receiver and easy to build a network system by installer.
Model | ND6110B |
InputInterface | 2xHDMI |
FrequencyBandwidth | 225MHz/ up to standard with HDCP :HDMI 1.3 |
SupportInputFormat |
480i,576i,720p@50/60,1080i@50/60,1080p@24/25/30, 1080p50/60 |
SDIOutInterface | 2x BNC(SD-SDI/HD-SDI/3G-SDI) |
SDI SignalRange | 0.8Vp-p |
SDI Impedance | 75ohms |
SDI CouplingType | AC Coupling |
SDI signal jitter(typical value) | SD-SDI≤0.1 UI HD-SDI≤0.2UI 3G-SDI≤0.4 UI |
Max.OutputCoaxLength |
Belden1694A SD-SDI 400m/ 1300ft ;HD-SDI 200m/ 600ft ;3G-SDI140m/ 450ft |
PowerSupply | 12VDC ,1Aw/LockingPower Connector |
PowerConsumption | 3~6 Watts |
OperatingTemperature | -10°C~60°C/14°F~140°F |
StorageTemperature | -30°C~70°C/-22°F~158°F |
RelativeHumidity | 20~90%RH(Non-condensation) |
Dimension | 112× 117× 25 mm / 4.40× 4.46× 0.98 in |
Weight | 280g |
Connection diagram
Order information
Part No | Description of product | Unit |
ND-6110B | HDMI to SDI Converter | piece |
