| Place of Origin: | SHENZHEN,CHINA |
| Brand Name: | NEWBRIDGE |
| Certification: | CE,FCC |
| Model Number: | ND-PD3101-af |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | packing can be done by customer's requested, usually used in carton |
| Delivery Time: | According to the quantiy and stocking , 3-4 working days after payment |
| Payment Terms: | T/T , Western Union |
| Supply Ability: | According to the different products , the monthly output is different |
| DC Output: | 12V,1A | Size: | 88*30*26mm |
|---|---|---|---|
| Operating Temp.: | -10ºC-45ºC | Operating Hum.: | 10%-90% |
| Storage Temp.: | -40ºC-70ºC | Standard: | IEE802.3af |
Specification
| Standard | IEEE 802.3, IEEE 802.3U, IEEE 802.3X,IEEE 802.3AF |
| Port | 10/100M RJ45 |
| DC Interface | |
| Media | 10BASE-T:3/4/5 UTP CABLE(≤100m) |
| 10BASE-TX: 5 UTP CABLE(≤100m) | |
| LED indicator | POWER |
| DC output | 12V,1A |
| RJ45 POE POWERED | 4,5+;7,8- pair |
| 1,2+;2,6-pair | |
| Size(L*W*H) | 88*30*26mm |
| Operating Temp. | -10ºC-45ºC |
| Storage Temp. | -40ºC-70ºC |
| Operating Hum. | 10%-90%,No condensation |
| Storage Temp. | 5%-90%, No condensation |
| EMC | CE Mark,commercial, FCC part 14 Class B |
Application Diagram
Order Information
| Part No | Description of product | Unit |
| ND-PD3101-af | IEEE802.3af Standard | 1pcs |
